Axles are defined by a central shaft which revolves a wheel or a gear. The axle on wheeled motor vehicles can be fixed to the wheels and rotated with them. In this particular case, bearings or bushings are provided at the mounting points where the axle is supported. On the other hand, the axle could be connected to its surroundings and the wheels may in turn turn around the axle. In this instance, a bushing or bearing is situated in the hole within the wheel to be able to allow the wheel or gear to rotate around the axle.
With trucks and cars, the term axle in several references is used casually. The word normally means shaft itself, a transverse pair of wheels or its housing. The shaft itself turns together with the wheel. It is normally bolted in fixed relation to it and referred to as an 'axle shaft' or an 'axle.' It is equally true that the housing surrounding it that is usually known as a casting is also called an 'axle' or occasionally an 'axle housing.' An even broader sense of the word refers to every transverse pair of wheels, whether they are connected to one another or they are not. Therefore, even transverse pairs of wheels in an independent suspension are frequently known as 'an axle.'
The axles are an essential component in a wheeled vehicle. The axle serves to transmit driving torque to the wheel in a live-axle suspension system. The position of the wheels is maintained by the axles relative to one another and to the motor vehicle body. In this system the axles must likewise be able to bear the weight of the motor vehicle plus whichever cargo. In a non-driving axle, as in the front beam axle in some two-wheel drive light vans and trucks and in heavy-duty trucks, there will be no shaft. The axle in this situation works only as a steering component and as suspension. A lot of front wheel drive cars consist of a solid rear beam axle.
The axle works just to transmit driving torque to the wheels in several kinds of suspension systems. The position and angle of the wheel hubs is part of the functioning of the suspension system seen in the independent suspensions of newer SUVs and on the front of several new light trucks and cars. These systems still consist of a differential but it does not have attached axle housing tubes. It could be fixed to the motor vehicle frame or body or likewise can be integral in a transaxle. The axle shafts then transmit driving torque to the wheels. The shafts in an independent suspension system are like a full floating axle system as in they do not support the motor vehicle weight.
To finish, in reference to a motor vehicle, 'axle,' has a more ambiguous description. It means parallel wheels on opposing sides of the vehicle, regardless of their mechanical connection kind to one another and the motor vehicle body or frame.
